| category: | metering |
| created: | 2024-02-27 |
| last build: | #2 |
| build date: | 2024-03-28 |
| doc file: | |
| Bar Meters, displays for maximum, minimum, average (DC amount), momentary value (volt or dBV) | |
| category: | metering |
| created: | 2024-02-27 |
| last build: | #2 |
| build date: | 2024-03-28 |
| doc file: | |
| Bar Meters, displays for maximum, minimum, average (DC amount), momentary value (volt or dBV) | |
| category: | metering |
| created: | 2024-02-27 |
| last build: | #3 |
| build date: | 2024-03-28 |
| doc file: | |
| Bar Meters, displays for maximum, minimum, average (DC amount), momentary value (volt or dBV), poly and mono inputs | |
| category: | metering |
| created: | 2024-02-27 |
| last build: | #2 |
| build date: | 2024-03-28 |
| doc file: | |
| Bar Meters, displays for maximum, minimum, average (DC amount), momentary value (volt or dBV), poly and mono inputs | |
| category: | utility |
| created: | 2019-08-17 |
| last build: | #3 |
| build date: | 2022-02-20 |
| doc file: | |
| Two push buttons deliver signal while pushed down, one toggle button with both normal and inverted signal out jacks. Output voltage is 5.0 Volts (On) or 0.0 Volts (Off). | |
| category: | utility |
| created: | 2019-08-17 |
| last build: | #3 |
| build date: | 2022-02-20 |
| doc file: | |
| Four push buttons deliver signal while pushed down, two toggle buttons with both normal and inverted signal out jacks. Output voltage is 5.0 Volts (On) or 0.0 Volts (Off). | |
| category: | switches |
| created: | 2023-06-21 |
| last build: | #1 |
| build date: | 2023-06-21 |
| doc file: | |
| Eight mono signal switches controlled by push buttons. When no cable is connected to section's input, output delivers 5 volts if button is pushed. | |
| category: | utility |
| created: | 2019-08-31 |
| last build: | #5 |
| build date: | 2022-03-03 |
| doc file: | |
| Checks a control voltage to match different conditions (<0, =0, >0, >1.0, >2.5, >5.0 volts). Results are given as gate out signals (0 or 5 V) and are signalized with LEDs. | |
| category: | metering |
| created: | 2019-08-17 |
| last build: | #9 |
| build date: | 2022-04-17 |
| doc file: | |
| Slim triple digital DC volt meter. Displays control voltage value or tone, that is represented by CV value. There is a choice of 0 to +10 or -2 to +8 pitch voltage range. | |
| category: | source |
| created: | 2019-12-12 |
| last build: | #7 |
| build date: | 2023-05-21 |
| doc file: | |
| Eight CV sources, Knob ranges 1, 3, 5 or 10 volts, base offset 0,-3, -5 volts, Quantizing for exact halftones possible, Offset input usable for key tracking, Offset amount adjustable. Knobs can be preset with one of eight tonal modes. | |
| category: | sequencer |
| created: | 2022-12-08 |
| last build: | #6 |
| build date: | 2024-07-08 |
| doc file: | |
| Cascadable one-channel sequencer with one to eight steps. Available functions: Quantizing, Glide, Legato, Limiting, Ratcheting. | |
| category: | cv processor |
| created: | 2023-04-02 |
| last build: | #6 |
| build date: | 2023-04-21 |
| doc file: | |
| This module simulates a bouncing ball in real time. Analog and digital output signals are usable to control oscillators, filters and so on. | |
| category: | cv processor |
| created: | 2022-02-20 |
| last build: | #3 |
| build date: | 2022-02-28 |
| doc file: | |
| Eight gate channels, linkable, controllable with pulses in toggle mode or CV in static mode. | |
| category: | sequencers |
| created: | 2024-01-28 |
| last build: | #6 |
| build date: | 2024-02-22 |
| doc file: | |
| Unusual sequencer, uses
Gray Codes. Main features: - Steps count can be set from 1 to 256. - Step trigger by CV or push button. - Single or cyclic step sequence. - Restart by CV, push button and automatically. - Step direction can be reversed by CV, by toggle button and automatically. - Digital outputs for new cycle start and Gray Code bits. - Analog outputs for step number, code number and code value. | |
| category: | visualizers |
| created: | 2023-06-22 |
| last build: | #2 |
| build date: | 2023-06-24 |
| doc file: | |
| Displays active notes of a poly CV signal as keys on a keyboard. | |
| category: | cv processor |
| created: | 2019-08-30 |
| last build: | #3 |
| build date: | 2022-02-23 |
| doc file: | |
| Transforms an analogue KEYB IN voltage (-10 to +10 v) to a logical signal (0 or 5 v) at one of twelve output jacks. KEYB IN voltage is also sent to KEYB THROUGH output jack. Other output jacks deliver a NORMALIZED KEYB IN voltage (0 to 1 v) and OCTAVE voltage. | |
| category: | visualizer |
| created: | 2021-12-11 |
| last build: | #3 |
| build date: | 2022-02-24 |
| doc file: | |
| LED show user CV input state with red or blue light related to a adjustable threshold value. All labels are editable. | |
| category: | cv processor |
| created: | 2022-03-20 |
| last build: | #6 |
| build date: | 2022-03-28 |
| doc file: | |
| Linear Feedbacked Shift Register is a pseudo random CV generator. It is based on a design of Italian mathemathic Leonardo Fibonacci. | |
| category: | cv processor |
| created: | 2019-08-31 |
| last build: | #5 |
| build date: | 2022-02-28 |
| doc file: | |
| Clips an input signal at set limits. There are independent upper and lower limits. Clipping activates LEDs and gate outputs. In hold mode a clipping event gets memorized. | |
| category: | logic |
| created: | 2019-08-28 |
| last build: | #4 |
| build date: | 2022-03-03 |
| doc file: | |
| Boolean device with eight inputs, two outputs and selectable functions either AND or OR. Each input signal can be inverted by a toggle button, before it is indicated and processed. Logical result is available both as normal and inverted signal (0 or 5 V). | |
| category: | utility |
| created: | 2023-05-11 |
| last build: | #2 |
| build date: | 2023-05-16 |
| doc file: | |
| Master Button is destined for use with Adroit Synthesis Tandem module. It extends Tandem's capability with operating other controls by CV, that are normally operated only manually. | |
| category: | utility |
| created: | 2023-05-11 |
| last build: | #3 |
| build date: | 2023-05-15 |
| doc file: | |
| Master Knob is destined for use with Adroit Synthesis Tandem module. It extends Tandem's capability with operating other controls by CV, that are normally operated only manually. | |
| category: | utility |
| created: | 2023-05-11 |
| last build: | #4 |
| build date: | 2023-05-16 |
| doc file: | |
| Master Radio is destined for use with Adroit Synthesis Tandem module. It extends Tandem's capability with operating other controls by CV, that are normally operated only manually. | |
| category: | utility |
| created: | 2023-05-11 |
| last build: | #4 |
| build date: | 2023-05-15 |
| doc file: | |
| Master Slider is destined for use with Adroit Synthesis Tandem module. It extends Tandem's capability with operating other controls by CV, that are normally operated only manually. | |
| category: | controller |
| created: | 2019-08-28 |
| last build: | #8 |
| build date: | 2024-05-12 |
| doc file: | |
| Multi Divider contains six counters, that can vary in function. Each counter can operate once (as timer) or continuously (frequency divider). With LINK option a continuously working counter can trig following counter. Preset values are possible from 1 to 9999. | |
| category: | utility |
| created: | 2021-12-10 |
| last build: | #3 |
| doc file: | |
| N-Klik offers a radio button set. Number N of buttons/inputs/outputs may be set from 2 to 8. Buttons can be activated by clicking onto it or by a CV in signal. CV out #1 to #8 send a 5 volts gate signal, when active, otherwise 0 volts. Channel labels are editable. Highlighted labels signalize active button. | |
| category: | cv processor |
| created: | 2022-04-27 |
| last build: | #1 |
| build date: | 2022-04-27 |
| doc file: | |
|
The job of this tiny module is to manipulate signal's DC amount.
Four algorithms calculate an offset, that shifts signal's zero line.
Additional offset can be set manually or by CV. This module can process all kinds of signals without level limitation. However, automatic offset compensation is only useful with audio signals. | |
| category: | oscillator |
| created: | 2023-05-31 |
| last build: | #3 |
| build date: | 2023-06-01 |
| doc file: | |
| A slim hybrid analog-digital oscillator with only basic functions, octave offset switchable from -15 to +5, optionally Voltage mode with +2 octaves offset, frequency from around 0 up to 20,000 Hz. | |
| category: | oscillator |
| created: | 2023-05-27 |
| last build: | #6 |
| build date: | 2023-06-09 |
| doc file: | |
| A hybrid analog-digital oscillator, frequency from around 0 up to 20,000 Hz, optionally Voltage mode with +2 octaves offset, octave offset switchable from -15 to +5, tone offset 0 to 13 half tones, fine tuning -99 to +99 cents, envelope CV input with real amplitude modulation capability, either bipolar or unipolar output signal. | |
| category: | oscillator |
| created: | 2023-05-30 |
| last build: | #4 |
| build date: | 2023-06-01 |
| doc file: | |
| A hybrid analog-digital oscillator, frequency from around 0 up to 20,000 Hz, optionally Voltage mode with +2 octaves offset, octave offset switchable from -15 to +5, tone offset 0 to 13 halftones, fine tuning -99 to +99 cents, env input with real amplitude modulation capability, either bipolar or unipolar output signal, CV inputs for FM, restart (hard sync), PWM, several digital and bar meters for measurement of frequency, pitch voltage, cycle time. | |
| category: | utility |
| created: | 2024-07-21 |
| last build: | #6 |
| build date: | 2024-07-25 |
| doc file: | |
|
PANda is a panner with several common functions as modulatad or stepped panning.
A special function is the emulation of pipes location of a church organ. This means that a large (low pitch) or
small (high pitch) pipe is in the center. Pipes for ascensing or descensing halftones are placed left and right
beside center with rising distance. The module supports enlarged stereo processing. | |
| category: | switches |
| created: | 2023-03-14 |
| last build: | #1 |
| build date: | 2023-03-15 |
| doc file: | |
| Switches one poly input signal to one of eight output poly jacks. Selection is done either by eight GATE IN signals or a CV IN voltage. TRIG OUT sends a pulse at every valid selection change. HOLD function is available. | |
| category: | switches |
| created: | 2023-03-14 |
| last build: | #1 |
| build date: | 2022-03-15 |
| doc file: | |
| Switches one of eight poly input signals to a single poly output jack. Selection is done either by eight GATE IN signals or a CV IN voltage. TRIG OUT sends a pulse at every valid selection change. HOLD function saves last value from last selected input. | |
| category: | switches |
| created: | 2023-12-15 |
| last build: | #2 |
| build date: | 2023-12-16 |
| doc file: | |
| Eight poly signal switches controlled by toggle buttons. When no cable is connected to section's input, output can deliver 5 volts if section button is toggled on and module is in Gate mode. All outputs can be muted with Mute toggle button. | |
| category: | controller |
| created: | 2019-08-29 |
| last build: | #4 |
| build date: | 2022-03-17 |
| doc file: | |
| Each of six channels creates a five volts pulse each time, when input voltage exceeds 2.5 volts (rising ramp). So a trigger pulse will be converted to a gate signal. Gate pulse duration can be adjusted from 1 ms to 10 sec within three ranges. Channel inputs may be coupled with LINK toggle buttons. Easy copying of adjusted time to linked channels with COPY button. | |
| category: | cv processor |
| created: | 2022-03-10 |
| last build: | #4 |
| build date: | 2022-03-12 |
| doc file: | |
| Dual slope VCA with pre amp and limiter. Slope time up to 20 minutes. | |
| category: | envelope generator |
| created: | 2022-03-10 |
| last build: | #3 |
| build date: | 2022-03-15 |
| doc file: | |
| Dual slope envelope generator/LFO. Slope time up to 10 minutes. | |
| category: | sequencer |
| created: | 2019-08-27 |
| last build: | #29 |
| build date: | 2023-04-25 |
| doc file: | |
| Step generator. Can be used together with Tone Event module to build up a step sequencer. Several Steppers may be cascaded up to 999 steps, even each with less than 8 steps. | |
| category: | utility |
| created: | 2023-05-07 |
| last build: | #3 |
| build date: | 2023-05-08 |
| doc file: | |
| A clock. Five skins are available: Four analog dial clocks and a digital clock with calendar displays. | |
| category: | mixers |
| created: | 2024-02-17 |
| last build: | #2 |
| build date: | 2024-02-17 |
| doc file: | |
| Simple mixer without controls. Signal sum can be output either unchanged or normalized. | |
| category: | switches |
| created: | 2019-08-30 |
| last build: | #6 |
| build date: | 2023-03-15 |
| doc file: | |
| Switches one analogue input signal to one of eight output jacks. Selection is done either by eight GATE IN signals or a CV IN voltage. TRIG OUT sends a pulse at every valid selection change. HOLD function is available. | |
| category: | switches |
| created: | 2019-08-30 |
| last build: | #6 |
| build date: | 2022-03-15 |
| doc file: | |
| Switches one of eight analogue input signals to a single output jack. Selection is done either by eight GATE IN signals or a CV IN voltage. TRIG OUT sends a pulse at every valid selection change. HOLD function saves last value from last selected input. | |
| category: | utility |
| created: | 2022-12-14 |
| last build: | #22 |
| doc file: | |
|
Time Assistant is a digital clock with two extra functions: 1. A target date / time is set, for example a birthday or the planned project release day. The module will show you remaining time. 2. A remaining time interval is set. The module will treat it as countdown timer and show you resulting date with it's target display. When remaining time has reached zero, an alarm occurs. | |
| category: | switches |
| created: | 2023-06-21 |
| last build: | #1 |
| build date: | 2023-06-21 |
| doc file: | |
| Eight mono signal switches controlled by toggle buttons. When no cable is connected to section's input, output delivers 5 volts if button is toggled on. | |
| category: | controller |
| created: | 2019-08-27 |
| last build: | #8 |
| doc file: | |
| Together with Stepper this module can be used as stage of a step sequencer. Cabling is simplified with TROUGH outputs for KEYB IN, GATE IN and ARP IN. ARP input can be used to produce multi notes during one sequencer step. (ratchating) ARP function is controllable with ARP ENABLE input. An installed LCD shows tone, that is set up with TUNE knob, RANGE counter and OCTAVE counter. With EXACT toggle button tone will be quantized to exact halftone level. | |
| category: | cv processor |
| created: | 2019-08-31 |
| last build: | #3 |
| doc file: | |
| Transforms signals from an input band with Min1 and Max1 to an output band with Min2 and Max2. | |
| category: | utility |
| created: | 2021-12-14 |
| last build: | #1 |
| doc file: | |
| TrigTrap indicates trigger pulses. Every time a CV trig in signal exceeds a threshold voltage or falls below that threshold, a "trap" catches this state and a +5 volts gate signal will be output. User gets an optical information with the highlighted label. These labels are editable. A rising or falling ramp may be selected. There is an all trap, which gets activated when one of the other eight traps recognizes a trigger pulse. | |
